Support MP 3000 HV – Multi Source Player

System requirements
(For playing high resolution audio files up to the maximum sampling rate)
– Intel Core 2 @ 1,6 GHz or higher or a comparable AMD Processor.
– 1 GB RAM
– USB Interface
– Microsoft Windows 10, 8.1, 8, 7 or Windows XP or MAC OS X 10.6.4 or above until OS X 10.9
– (OS X 10.10 only with disabled signature  interrogation. For details please refer the support area …)

Note:
MAC operating systems higher than OS X 10.10 no longer support the asynchronous USB 2 Mode
of the USB audio chip used in the MP 3000 HV.

Support

Catalogue

Catalogue HV-Series

User manual

User manual MP 3000 HV

Driver

System requirement
Installation manual USB-driver

Specifications

CD-Player

Formats
CD/DA, CD-R, CD-RW, CD Text
Frequency range + Dynamics
2 Hz - 20 kHz / 100 dB

Streaming Client

Formats
MP3 , WMA, AAC, OGG Vorbis,
FLAC (192/32 over LAN), WAV (192/32 over LAN)
AIFF (192/32 over LAN), ALAC (96/24 over LAN)
Supported media servers
UPnP 1.1, UPnP-AV and DLNA-kompatible Server,
Microsoft Windows Media Connect Server (WMDRM 10),
vTuner Internet Radio Service, DLNA-compatible Server
Features
Auto network config,
Internet Radio Station database (automatic updates)

Tuner

FM Radio
87,5 - 108 MHz
Sensitivity
1,3 μV
Overload margin
> 125 dB
Stereo overload damping
40 dB
RDS-Display
Station name, Radio text

Connections

Analogue outputs unbalanced (RCA)
2,5 Veff / 50 Ohms
Analogue outputs balanced (XLR)
5,0 Veff / 50 Ohms
Digital outputs
1 x co-ax, IEC 60958 (LPCM)
Digital inputs
1 x AES-EBU with 192/24, 5 x S/P-DIF:
2 x high quality BNC 192/24
1 x Standard-Coax and 2 opt. TOS-Link 96/24
1 x USB Device Mode in USB Class1 (max. 96/24)
1 x USB Class2 Mode (max. 192/32),
Assists asynchronus (USB2 Mode) + synchronus (USB1 Mode) datatransfer
2 x USB Master-Mode for USB-Mass storage (Stick or HDD)

D/A Converter

Principle
Double-Differential-Quadruple-Converter with 4 D/A-converters per channel,
32-Bit Sigma Delta, 352,8 kSps/384 kSps
Upsampling
freely programmable signal processor with four selectable oversampling algorithms.
FIR short, FIR long, Bezier/IIR, Bezier
Analogue filter
Phase-linear Bessel fi lter 3rd Order with 60 or 120 kHz cut off frequency
Frequenzgangfrequency responce
2 Hz - 20 kHz / (44,1 kSps)
2 Hz - 22 kHz / (48,0 kSps)
2 Hz - 40 kHz / (96,0 kSps)
2 Hz - 80 kHz / (192,0 kSps)
Total harmonic distortion
< 0,001 %
Signal : noise ratio
116 dB
Channel separation
110 dB

Mains / Accessories / Dimensions

Mains
2 x 110-120 V or 220-240 V, 50 - 60 Hz, 40 W
Standby
< 0,5 W
Remote control
FD 100, bi-directional radio remote control system
Accessories
WLAN aerial, RF-aerial, charger for FD 100
BNC / RCA adapter
Dimensions (H x W x D)
17 x 46 x 46 cm
Weight
26 kg
Finishes
Case: silver laquer 47 or titanium laquer 64
Technical modifications reserved
